Application Field
-
Semiconductor Industry
-
Functional Film Industry
-
Lithium Battery Industry
-
Photovoltaic Industry
-
Electronics Industry
-
Washing Industry
-
Textile Industry
-
Soft Packaging Industry
-
Advertising Industry
Product Characteristics
1. Single-point horizontal on-line electrostatic detector
2. It has the characteristics of high precision, high stability, scalability and easy installation
3. Widely used in lithium battery, photovoltaic, soft package and advertising industries 4 Its best recognition ability can reach within ±50V, and its resolution accuracy is ±1V
Performance Parameter
- ModelYC-J130-03 / YC-J130-10 / YC-J130-30
- Reference Distance25mm (±1mm) / 25mm (±1mm) / 25mm (±1mm)
- Measuring Distance25mm (±1mm) / 25mm (±1mm) / 25mm (±1mm)
- Measuring Range0-±3KV / ±50-±10KV / ±100-±30KV
- Error Range＜5% / ＜5% / ＜5%
- Operating Current20mA～60mA / 20mA～60mA / 20mA～60mA
- Operating Ambient Temperature0℃～50℃
- Operating Ambient Humidity0%RH～60%RH
- Communication InterfaceRS485
- Communication Distance＜300m
- Input Voltage24V±10%
- Minimum Display Unit1V (minimum) to 100V (maximum), depending on the product range
- Output Voltage0.4V-4.9V
- Output Current4mA-16mA
- Housing MaterialPC
- Metal Part MaterialSUS
- Cable MaterialPVC
- WeightApproximately 445g
- Sampling Period1ms
- Response Time＜0.1s
Product Size
